Professional zinc alloy, aluminum alloy die casting
Mold design, mold opening, die casting
We invite you to provide design drawings or samples for joint development. We will manufacture the most satisfactory products for you with the most honest service and reasonable prices.
Main business items:
- Zinc alloy die-casting, aluminum alloy die-casting, precision die-casting
- Precision CNC lathes, milling and drilling machines, various processing, vibration grinding, manual polishing and grinding
- Various colors of coating/painting (liquid, powder), electrophoretic deposition, non-chrome treatment-special nano-baking paint and anodizing
*Comply with ROHS standard and salt spray test as required。 - Electroplating processing (chemical nickel, black tin nickel, satin nickel, trivalent chromium, nickel, gold, bronze, ancient red copper,etc.)
*Comply with ROHS standard and salt spray test as required。
SHENG CHANG's features
The density of the die-cast finished product is uniform, the product is not easy to be broken or deformed, the weight is stable, and the surface is uniform and smooth.
Sheng Chang integrates precision CNC machining, drilling and tapping, in-hole grinding, (overcoming the precision requirements of straight line, plane, arc, concentricity, and thickness), vibration grinding, manual polishing and grinding, various color of electroplating, electrophoretic deposition, anodizing, non-chromic acid surface treatment (in accordance with ROHS, environmental protection requirements, product corrosion resistance and salt spray test) and parts foundry assembly.
Our company adopts consistent operations to achieve fast delivery and the goal of reducing customers’ inventory.
OEM/ODM Inquiries are Welcome!
CONTACT USSTEP 01
Mold making
STEP 02
Die casting
STEP 03
Processing
STEP 04
Painting/Coating
STEP 05
Electroplating
STEP 06
Package
STEP 07
Inspection
STEP 08
Shipment
Production Process
All kinds of customization needs are welcome!
Business Scope
- 3C
- Security products
- Communication products
- Automotive products
- Medical products
- Sports products
- Lighting
- Connector
- Heat sink
- Computer peripheral components
Business Percentages
- computer products--50%
- Other electronic products--50%
Related cases
NOTE BOOK類 | CHARGER BOARD | INVERTER | POWER CPU | LVDS CARD | IR BOARD |
LCD MAIN BOARD | LED BOARD | RAM CARD | DATA BOARD | BATT BOARD | |
DVR MAIN BOARD | USB BOARD | CARD READER | AUDIO BOARD | ISDN MODEM (incl. assembly) | |
PC | 25" HDD external box (incl. assembly) |
PC/MAC external use FDD (incl. assembly) |
DOCKING (incl. assembly) |
PORT REPILICATOR (incl. assembly) |
PCMCIA CARD (incl. assembly) |
35" HDD external box (incl. assembly) |
SATA HDD external box (incl. assembly) |
||||
Communication | DVBT.ATSC TV digital box (incl. assembly) |
GPS (incl. assembly) |
CAR GPS (incl. assembly) |
ADSL MODEM (incl. assembly) |
DVBT 3.5" (incl. assembly) |
Images | MPEG 4 | KVM (incl. assembly) | Electronic books (incl. assembly) |
HDMI LITE BOX (incl. assembly) |
DVI LITE BOX (incl. assembly) |
Monitors | LCD TV MAIN BOARD | DVR MAIN BOARD | CCD BOARD | ||
Medicine | LOW-FREQUENCY MEDICINE MEDICAL DEVISES |
EAR THERMOMETER | BLOOD GLUCOSE METER | BODY FAT METER / BLOOD PRESSURE METER |
|
LED | LED CAR LIGHTS | ROPE LIGHTS | TRAFFIC LIGHTS | OUTDOOR SIGNBOARD APPLICATION | SPOT LIGHTS |
Instruments | OSCILLOSCOPE | POWER SUPPLY | L.C.R.TESTER | ||
Electronic and consumer products | SENSORS BOARD | DRIVER BOARD | USB DRIVER BOARD | BARCODE READER |
Aluminum Alloy Die Casting
Feature
- Light-weight
- Superior erosion resistance
- Superior thermal conductivity
- Outstanding machining characteristics
- Superior intensity and rigidity
- Easy to recycle for re-melting
- Superior environment-friendly metal material
Advantages
- Aluminum alloys usually are machined by cold chamber die casting machines
- Oxide films protect interior from oxidation
Aluminum Alloy Composition Table
JIS | Cu | Si | Mg | Zn | Fe | Mn | Ni | Sn | Al |
AD1-1(ADC1) | 1.0Max | 11.0-13.0 | 0.3Max | 0.5Max | 0.9Max | 0.3Max | 0.5Max | 0.1Max | BAL |
AD3-1(ADC3) | 0.6Max | 9.0-10.0 | 0.4-0.6 | 0.5Max | 0.9Max | 0.3Max | 0.5Max | 0.1Max | BAL |
AD5-1(ADC5) | 0.2Max | 0.3Max | 4.1-8.5 | 0.1Max | 1.1Max | 0.3Max | 0.1Max | 0.1Max | BAL |
AD6-1(ADC6) | 0.1Max | 0.1Max | 2.-4.0 | 0.4Max | 0.6Max | 0.4-0.6 | 0.1Max | 0.2Max | BAL |
AD10-1(ADC10) | 2.0-4.0 | 7.5-9.5 | 0.3Max | 1.0Max | 0.9Max | 0.5Max | 0.5Max | 0.2Max | BAL |
AD10Z-1(ADC10Z) | 2.0-4.0 | 7.5-9.5 | 0.3Max | 3.0Max | 0.9Max | 0.5Max | 0.5Max | 0.2Max | BAL |
AD12-1(ADC12) | 1.5-3.5 | 9.6-12.0 | 0.3Max | 1.0Max | 0.9Max | 0.5Max | 0.5Max | 0.2Max | BAL |
AD12Z-1(ADC12Z) | 1.5-3.5 | 9.6-12.0 | 0.3Max | 3.0Max | 0.9Max | 0.5Max | 0.5Max | 0.2Max | BAL |
AD14-1(ADC14) | 4.5-5.0 | 16.0-18.0 | 0.5-0.65 | 1.5Max | 0.9Max | 0.5Max | 0.3Max | 0.3Max | BAL |
A380 | 3.0-4.0 | 7.5-9.5 | 0.10Max | 3.0Max | 2.0Max | 0.5Max | 0.5Max | 0.35Max | BAL |
A356 | 0.25Max | 6.5-7.5 | 0.25-0.45 | 0.35Max | 0.5Max | 0.3Max | - | - | BAL |
Zinc Alloy Die Casting
Feature
- Superior machinery value
- High-precision dimensions and accuracy
- Thin walls have excellent tension resistance
- Superior corrosion resistance
- Superior electric and heat conductivity
Advantages
- Zinc alloys usually machined by hot chamber die casting machines
- Oxide films protect interior from oxidation
Zinc Alloy Composition Table
ALLOY | Al | Mg | Cu | Fe | Pb | Cd | Sn | Zn |
ZAMAK-3 | 3.5-4.3 | 0.02-0.05 | 0.25Max | 0.1Max | 0.005Max | 0.004Max | 0.003Max | BAL |
ZAMAK-5 | 3.5-4.3 | 0.03-0.08 | 0.75-1.25 | 0.1Max | 0.005Max | 0.004Max | 0.003Max | BAL |
ZDC-1 | 3.5-4.3 | 0.02-0.06 | 0.75-1.25 | 0.1Max | 0.005Max | 0.004Max | 0.003Max | BAL |
ZDC-2 | 3.5-4.3 | 0.02-0.06 | 0.25Max | 0.1Max | 0.005Max | 0.004Max | 0.003Max | BAL |
ZDC-3 | 3.5-4.3 | 0.02-0.06 | 0.35Max | 0.1Max | 0.008Max | 0.004Max | 0.003Max | BAL |
ZDC-4 | 3.5-4.3 | 0.02-0.06 | 0.75-1.25 | 0.1Max | 0.008Max | 0.004Max | 0.003Max | BAL |
